Originally Posted by shadycrew31

If you are running a stock greddy setup factory RX-8 plugs will do fine.

Have you checked your AC condenser and cleaned it out? Try doing that before you go buying $600 worth of radiator.

I see 180* cruise temps with an upgraded turbo, in texas heat.

Originally Posted by RonniEdwards

Thank you for your help. But since I have FI (Greddy) I still won't have to re-tune on a battery reset? That one bothers me the most so I have to check and recheck.

Also, I didn't know you used different plugs for FI.

Originally Posted by RonniEdwards

Well I'm having cooling issues and I THINK it may be my thermostat due to my radiator seems fine, no leaks, hoses perfect and all that jazz. So i figured why not since i have FI and the like. The AC condenser is still lookin new as well. Everything looks new and seems new, but isn't acting new.

Thats part of what got me debating a better radiator, that and being in the desert. Thank you for the tip though.

Originally Posted by WreakLoosE

Hay guys... I got a question on fan Trigger Temps..

I have an access port and I know you can adjust the fan trigger points with the AP.. Im just wondering how to do this with the tuner race program, and what are good points for idle, low speed driving etc.. Just a simple how to if that is available. I looked for something and I cannot find anything on it..

Oh yea Bonus question: Is there a way to control the Drive by wire throttle imput with the access port as well? If so how is this done with the AP? Or does an addition throttle controller fix this issue? Any thoughts on this would help as well..

Thanks..

Originally Posted by 1.3_LittersOfFurry

Are you asking how to adjust it in atr, or how to load the map on your car?

Idle Post 15
https://www.rx8club.com/series-i-eng...eed-ap-215661/

When adjusting, keep in mind
Temps in celcius
Speed in kmh


My idle is set to 875rpm
Fans are 186/188/194*f

Some threads that helped me learn...

https://www.rx8club.com/series-i-eng...ssport-178635/

https://www.rx8club.com/series-i-maj...-120276/page6/

Originally Posted by WreakLoosE

Thank you sir.. Yes wanted to know how to adj. in atr

Originally Posted by mag10197

Hello. Let me just put out there that I do not know much about cars at all. I own a 2004 RX8. My boyfriend looked under the front of my car and there is this piece of plastic that looks like it is a shield to protect something. Mine is pretty ripped up.

Does anyone know what the name of this part is called? Should I take it into the shop? How important is this plastic shield?

Thank you in advance,
Melissa

Originally Posted by WreakLoosE

SO I was looking at this and I wanted to get an idea of the LTFT menu in the TR but I can find it..

I did a few data logs using MM info and I was wanted to know how to scale the MAF with what I got but I seem to be missing some information. OR looking in the wrong spot on the TR program. any help?

06-15-2012, 12:31 PM #4
oltmann
Registered User

Trader Score: (0)
Join Date: Sep 2010
Location: My parents basement
Posts: 522
Simple method:
Take some logs, the technique described in MMs thread is fine. You just need data from idle, cruising, 2nd gear full throttle, and 3rd or 4th full throttle.

Cleaning the MAF is a good idea.

Scaling the MAF table at the low end is the easiest way to eliminate fuel trims. Reducing fuel trims is important, because the long-term fuel trim (LTFT) that is developed under highway cruising conditions in closed-loop will affect full-throttle open-loop fuel delivery.

LTFTs are set over three ranges.
1-9 grams/second
9-20 g/sec
20-200 g/sec

Just select each range, hit m, and multiply the values by the error you are seeing in the log for that range.

For the last range, there is no need to scale the MAF beyond 100g/sec.

Iterate until the trims approach zero.

Adjust the fuel tables for gears 1-2 and 3-4 based on your full-throttle logs.

Iterate until you see the AFR you want. Best power is usually in the mid-13s, it is may be safer to aim for high 12s.

I find a visual log viewer like MegaLogViewer is a much easier way to view logs.

For the OMP, just increase the values in the load-based table.
I can't find it right now, but I have a Mazda research paper in which they measured oil delivery rate vs wall temperature. Temp decreases with increasing oil delivery, and then flat-lines.

In other words, there is an optimal point, but the only problem in going beyond the optimum is increased oil consumption. I have an OMP adapter/tank, and I like the smell of premixy exhaust, so have this table adjusted liberally.

Code:
3.00 3.00 3.00 4.00 5.00 5.00 6.00 7.00 8.00 8.00 9.00 10.00 10.00 11.00 12.00 15.00 19.00 19.00 21.00
5.00 5.00 5.00 6.00 7.00 7.00 8.00 8.00 9.00 10.00 10.00 11.00 12.00 13.00 15.00 18.00 21.00 25.00 29.00
7.00 7.00 7.00 8.00 8.00 9.00 9.00 10.00 11.00 11.00 12.00 13.00 13.00 15.00 17.00 21.00 25.00 30.00 36.00
9.00 9.00 9.00 9.00 10.00 10.00 11.00 11.00 12.00 12.00 13.00 14.00 15.00 17.00 20.00 24.00 29.00 35.00 42.00
11.00 11.00 11.00 11.00 12.00 12.00 12.00 13.00 13.00 14.00 14.00 15.00 17.00 20.00 23.00 28.00 34.00 39.00 45.00
12.00 12.00 13.00 13.00 13.00 13.00 14.00 14.00 15.00 15.00 16.00 17.00 19.00 23.00 27.00 33.00 38.00 42.00 46.00
14.00 14.00 14.00 15.00 15.00 15.00 15.00 16.00 16.00 17.00 17.00 19.00 21.00 25.00 31.00 36.00 41.00 44.00 48.00
16.00 16.00 16.00 16.00 17.00 17.00 17.00 17.00 18.00 18.00 19.00 20.00 23.00 28.00 34.00 39.00 43.00 46.00 49.00
18.00 18.00 18.00 18.00 18.00 18.00 18.00 19.00 19.00 20.00 20.00 21.00 24.00 29.00 35.00 41.00 45.00 48.00 51.00
20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 21.00 21.00 23.00 26.00 31.00 37.00 42.00 46.00 49.00 53.00
21.00 21.00 21.00 21.00 21.00 21.00 21.00 21.00 21.00 22.00 23.00 24.00 28.00 32.00 38.00 43.00 47.00 51.00 54.00
22.00 22.00 22.00 22.00 22.00 22.00 22.00 22.00 22.00 23.00 24.00 26.00 30.00 35.00 40.00 45.00 49.00 52.00 56.00
22.00 22.00 22.00 22.00 22.00 22.00 22.00 23.00 23.00 24.00 26.00 29.00 33.00 38.00 43.00 47.00 50.00 54.00 57.00
22.00 22.00 22.00 22.00 22.00 23.00 23.00 24.00 26.00 27.00 30.00 33.00 38.00 42.00 47.00 50.00 53.00 56.00 58.00
22.00 22.00 22.00 22.00 23.00 24.00 26.00 28.00 31.00 33.00 36.00 40.00 45.00 50.00 53.00 56.00 58.00 60.00 60.00
22.00 22.00 22.00 22.00 23.00 26.00 30.00 34.00 38.00 41.00 44.00 49.00 54.00 59.00 60.00 60.00 60.00 60.00 60.00
22.00 21.00 22.00 22.00 23.00 27.00 33.00 37.00 42.00 45.00 49.00 54.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00
Adjust the coil dwell times.

Done.

Not the way I do it, but I think this method is easy enough, and will probably give 95% of the improvements possible on an NA car.
