Ya that's what I'm afraid of but I was thinking I could play it dumb and simply complain about a lack of power. If my problem could be fixed with the Mazsport coils I would consider buying them but if I'm having a problem with ports opening then that is a little over my head.
#304
Power!!
11:1 is the rich end of the best torque range.
Nice and safe.
I actually found no additional power shooting for anything leaner (i tried all the way up to 12.2:1 on my car above 6500 RPM), so 11:1 is cheap insurance.
10.8:1 is where I figured the safe range would be on the Int-X since it is a little silly about fuel delivery when the density changes.
Nice and safe.
I actually found no additional power shooting for anything leaner (i tried all the way up to 12.2:1 on my car above 6500 RPM), so 11:1 is cheap insurance.
10.8:1 is where I figured the safe range would be on the Int-X since it is a little silly about fuel delivery when the density changes.
gtwr: I've seen this before when a cat. is plugged. I see the two dips when the intake runners open and it looks like it's not breathing well at top end. I tell your dealer you've been hearing that the cat. converters on these cars have been melting and clogging up. You'll want them to physically unbolt the cat. and look inside. It can get clogged without setting off a CEL if the back half of the element is melted after the O2 sensor. Don't let them tell you it would throw a CEL if it were bad because that's not always true.
It's also a good idea to replace the coils if you haven't anyway.
#305
Registered User
iTrader: (1)
Join Date: Jan 2007
Location: Mississauga, ON
Posts: 703
Likes: 0
Received 0 Likes
on
0 Posts
I setup an appointment at the dealership for Wednesday. I don't think the service guy had any idea what I was talking about as he asked "when does it happen?" I just said "always." I'm going to write a short letter to the mechanic to help explain it.
Oh, and I had been talking to the manager first (good guy) and I said I suspected it could be a partially clogged cat. His response was "could the Greddy exhaust have anything to do with it?" "No!" said I. I think the worst that could happen in this case is they decide they can't find anything wrong. Should my warranty be voided I think I'll just buy a turbo kit. :P
Oh, and I had been talking to the manager first (good guy) and I said I suspected it could be a partially clogged cat. His response was "could the Greddy exhaust have anything to do with it?" "No!" said I. I think the worst that could happen in this case is they decide they can't find anything wrong. Should my warranty be voided I think I'll just buy a turbo kit. :P
Last edited by qtwre; 01-28-2008 at 04:25 PM.
#306
Registered User
iTrader: (1)
Join Date: Jan 2007
Location: Mississauga, ON
Posts: 703
Likes: 0
Received 0 Likes
on
0 Posts
**** me! These people don't work unless there's a check engine light. I brought it in and left it with them, explained (in a letter) what was wrong and attached the dyno chart to illustrate what I was saying, and they just said there's nothing wrong because there's no CEL. I was apparently under the wrong impression that if you say something's wrong and show proof, they should poke around at the usual suspects to check for anything wrong.
I called another dealership to book an appointment about hard starts (which I get occasionally) and the service guy said if there's no CEL they can't help me.
I called another dealership to book an appointment about hard starts (which I get occasionally) and the service guy said if there's no CEL they can't help me.
#308
Registered User
iTrader: (1)
Join Date: Jan 2007
Location: Mississauga, ON
Posts: 703
Likes: 0
Received 0 Likes
on
0 Posts
Unfortunate for me. I'm not sure what to do now... If it's the cat do I take it off myself and bring it in to show them? Should I buy Mazsport coils? I wouldn't mind so much if this weren't a lease.
#309
Power!!
Tell them to specifically unbolt the cat. and look inside to verify that it's plugged or not. You'd be willing to pay them for their time if there's nothing wrong right? WTF??
Ask them if you'll get a cell when the shocks are dead or you flood your engine or when compression is low as in the recall to replace the motor? If the answer is no then maybe there is a chance there is something wrong with the car that doesn't necessarily set off the CEL and they need to get off their asses and do some work!!
Ask them if you'll get a cell when the shocks are dead or you flood your engine or when compression is low as in the recall to replace the motor? If the answer is no then maybe there is a chance there is something wrong with the car that doesn't necessarily set off the CEL and they need to get off their asses and do some work!!
#311
Registered User
iTrader: (1)
Join Date: Jan 2007
Location: Mississauga, ON
Posts: 703
Likes: 0
Received 0 Likes
on
0 Posts
That's actually a pretty good idea Shaun. Question though... as I've never looked through a cat, what should a functioning one look like? Is it a honeycomb that I should be able to see light through? If it isn't the cat and it turns out to be an intake port this could get expensive.
#312
Power!!
Here's a thread with some good info. Same problem you're experiencing.
PM DMP. I think he has some pictures.
https://www.rx8club.com/series-i-trouble-shooting-95/saga-bad-cat-mazdas-inaction-110322/
PM DMP. I think he has some pictures.
https://www.rx8club.com/series-i-trouble-shooting-95/saga-bad-cat-mazdas-inaction-110322/
#314
No respecter of malarkey
iTrader: (25)
The Mustang dyno graph is finally posted at the Cobb Tuning AccessPort thread link below.
The numbers are slightly different than what I recalled:
https://www.rx8club.com/showpost.php...&postcount=414
#317
Boosted Kiwi
iTrader: (2)
The Mustang dyno graph is finally posted at the Cobb Tuning AccessPort thread link below.
The numbers are slightly different than what I recalled:
https://www.rx8club.com/showpost.php...&postcount=414
The numbers are slightly different than what I recalled:
https://www.rx8club.com/showpost.php...&postcount=414
#319
No respecter of malarkey
iTrader: (25)
We didn't have time to try and work through them. The intake flow changed considerably between the previous dyno graph and this one. Enough to change the AFRs to the high 14s (14.7 AFR @ 8500 rpm/WOT makes me a bit nervous ), which is why I asked them to accommodate me on the dyno again and dial it back to a safer low 13s range.
