Trouble with putting shock back together.....Help

07-06-2008, 11:51 AM

#1

12oclock

Guest

Posts: n/a

Trouble with putting shock back together.....Help

So today we're lowering the 8 with tanabe GF210's and we have the back shocks off. But we're having trouble getting hte housing back on the shock with the new springs. When we try to push the washer, donut....all that stuff on to the shock so we can put the housing back on the shock compresses and we can't get it to come through the washer, donut etc. to secure the housing. Anyone run into this problem before? I did a search and found instructions on installation but nothing troubleshooting this problem. If anyone has a pic of exactly how everything goes back on the shock that would help too as I couldn't find any pics with active links. Thanks for any advice....................

Reply Like

07-06-2008, 12:11 PM

#3

12oclock

Guest

Posts: n/a

nah. the shock's good otherwise one of the other guys I'm working on it with would have pointed that out by now as they've done plenty of suspension work.

Reply Like

07-06-2008, 12:32 PM

#5

12oclock

Guest

Posts: n/a

Quote:

Originally Posted by dannobre

Spring compressor

lol, we're using one

The orange rubber bushing (not sure what to call it looks like a caterpilllar) for those of u who have done this is the problem. We can't get it to compress enough to get the shock to pop through the top of the housing enough to get the nut on.

Let me ask this, Just how much do we need to compress the spring? Like all the way>? Cause we haven't compressed it a whole lot yet.

Last edited by 12oclock; 07-06-2008 at 12:40 PM.

Reply Like

07-06-2008, 12:52 PM

#8

12oclock

Guest

Posts: n/a

Quote:

Originally Posted by rxaddict

http://69.108.208.137/ryang/modify/r...Suspension.pdf

Check page 26. This is where I got all my info when I did it...I'm not takin credit for it.

That's the bump stop. You'll need to cut it a bit so that you're not riding on it with the lowered setup

SO you cut the orange bushing when you did yours? By how much?

Reply Like

07-06-2008, 01:41 PM

#11

12oclock

Guest

Posts: n/a

Quote:

Originally Posted by rxaddict

pm'ed you. Gist of it: racing beat suggested cutting down by 1.75 inches, but they have less of a drop than the tanabes so I'm not sure. There's not much more to cut after that...

Cut it 1.75 and got it! I owe ya one man....thanks
