DeatschWerks dw200 in a 2004 RX-8 ???
Thread Starter
Registered
Joined: Aug 2019
Posts: 112
Likes: 8
From: Baton Rouge, Louisiana
DeatschWerks dw200 in a 2004 RX-8 ???
So my dw200 will arrive tomorrow. Honestly, I did very little research other than what was a good, proven high flow fuel pump used in the RX-8. Since ordering I've been reading up on the pumps used in our cars and it seems some things I'm reading are saying the high flow pumps wont work in the earlier models. Although I find other posts saying they're the best thing since sliced bread.Can someone give me a definitive answer on if I should install this pump tomorrow and if not why ? Thanks for taking the time.
Thread Starter
Registered
Joined: Aug 2019
Posts: 112
Likes: 8
From: Baton Rouge, Louisiana
I checked the codes and I now have a p2102....throttle actuator circuit? So I'm guessing I was experiencing limp mode. No matter how much gas I gave it i just limped along. Why would replacing the fuel pump cause this ? It was fine before ....
Thread Starter
Registered
Joined: Aug 2019
Posts: 112
Likes: 8
From: Baton Rouge, Louisiana
Problem SOLVED.
I removed the pump to check and see if maybe I made a mistake with install, but couldn't find anything wrong. So I reinstalled and performed an ESS reset. My thinking was that my fuel trims were jacked due to a rough idle, misfire , possible vacuum leak issue I've been dealing with and it looks like I may have been correct. After the rest she runs like a scalded dawg Very noticeable improvement in the low-midrange pick up/acceleration. The car just pulls so much stronger now.
I removed the pump to check and see if maybe I made a mistake with install, but couldn't find anything wrong. So I reinstalled and performed an ESS reset. My thinking was that my fuel trims were jacked due to a rough idle, misfire , possible vacuum leak issue I've been dealing with and it looks like I may have been correct. After the rest she runs like a scalded dawg Very noticeable improvement in the low-midrange pick up/acceleration. The car just pulls so much stronger now.
New Member
Joined: Dec 2022
Posts: 3
Likes: 0
I recently installed the dw200 myself and experienced similar issues (without doing the siphon modification like mazdamaniac). After revs in neutral the car tries to stall when reaching idle at 1k rpm again. I also got the p2102 fault code aswell as the System too lean fault code. How did you reset the ESS? Or did you clean it? Did you do the siphon modification. Thank you for your time.
that never ends as well as it could or should.
if you put a new factory pump in it the “runs like a scalded dog” result would be exactly the same. The general problem with doing a fuel pump swap on an S1 RX8 is there’s no way to replace the internal fuel filter. Because it was intended to swap out the entire fuel pump module which then replaces everything.
the alternative is to swap in an S2 pump module, which requires a few modifications to do and is documented on the forum. Because the Denso pump in ot is more reliable and close to thi output of the DW200 pump. More importantly, Mazda sells the internals separately on it like the filter, PRV, etc. The PRV is also a contained metal housing with everything inside. So it doesn’t require having to weld the plastic cap on like the S1 pump does.
the moral of the story being that some basic research/planning first is *always* the wise thing to do.
.
if you put a new factory pump in it the “runs like a scalded dog” result would be exactly the same. The general problem with doing a fuel pump swap on an S1 RX8 is there’s no way to replace the internal fuel filter. Because it was intended to swap out the entire fuel pump module which then replaces everything.
the alternative is to swap in an S2 pump module, which requires a few modifications to do and is documented on the forum. Because the Denso pump in ot is more reliable and close to thi output of the DW200 pump. More importantly, Mazda sells the internals separately on it like the filter, PRV, etc. The PRV is also a contained metal housing with everything inside. So it doesn’t require having to weld the plastic cap on like the S1 pump does.
the moral of the story being that some basic research/planning first is *always* the wise thing to do.
.
that never ends as well as it could or should.
if you put a new factory pump in it the “runs like a scalded dog” result would be exactly the same. Which is more accurately stated as it likely runs the same as all the other ~175 whp RX8s. The general problem with doing a fuel pump swap on an S1 RX8 is there’s no way to replace the internal fuel filter. Because it was intended to swap out the entire fuel pump module which then replaces everything.
the alternative is to swap in an S2 pump module, which requires a few modifications to do and is documented on the forum. Because the Denso 65C pump in it is more reliable and close to the output of the DW200 pump. More importantly, Mazda sells the internals separately on it like the filter, PRV, etc. The PRV is also a contained metal housing with everything inside. So it doesn’t require having to weld the plastic cap on like the S1 pump does.
the moral of the story being that some basic research/planning first is *always* the wise thing to do.
.
if you put a new factory pump in it the “runs like a scalded dog” result would be exactly the same. Which is more accurately stated as it likely runs the same as all the other ~175 whp RX8s. The general problem with doing a fuel pump swap on an S1 RX8 is there’s no way to replace the internal fuel filter. Because it was intended to swap out the entire fuel pump module which then replaces everything.
the alternative is to swap in an S2 pump module, which requires a few modifications to do and is documented on the forum. Because the Denso 65C pump in it is more reliable and close to the output of the DW200 pump. More importantly, Mazda sells the internals separately on it like the filter, PRV, etc. The PRV is also a contained metal housing with everything inside. So it doesn’t require having to weld the plastic cap on like the S1 pump does.
the moral of the story being that some basic research/planning first is *always* the wise thing to do.
.
Last edited by TeamRX8; Dec 9, 2022 at 09:02 AM.
Registered
Joined: Jan 2022
Posts: 59
Likes: 1
that never ends as well as it could or should.
if you put a new factory pump in it the “runs like a scalded dog” result would be exactly the same. Which is more accurately stated as it likely runs the same as all the other ~175 whp RX8s. The general problem with doing a fuel pump swap on an S1 RX8 is there’s no way to replace the internal fuel filter. Because it was intended to swap out the entire fuel pump module which then replaces everything.
the alternative is to swap in an S2 pump module, which requires a few modifications to do and is documented on the forum. Because the Denso 65C pump in it is more reliable and close to the output of the DW200 pump. More importantly, Mazda sells the internals separately on it like the filter, PRV, etc. The PRV is also a contained metal housing with everything inside. So it doesn’t require having to weld the plastic cap on like the S1 pump does.
the moral of the story being that some basic research/planning first is *always* the wise thing to do.
.
if you put a new factory pump in it the “runs like a scalded dog” result would be exactly the same. Which is more accurately stated as it likely runs the same as all the other ~175 whp RX8s. The general problem with doing a fuel pump swap on an S1 RX8 is there’s no way to replace the internal fuel filter. Because it was intended to swap out the entire fuel pump module which then replaces everything.
the alternative is to swap in an S2 pump module, which requires a few modifications to do and is documented on the forum. Because the Denso 65C pump in it is more reliable and close to the output of the DW200 pump. More importantly, Mazda sells the internals separately on it like the filter, PRV, etc. The PRV is also a contained metal housing with everything inside. So it doesn’t require having to weld the plastic cap on like the S1 pump does.
the moral of the story being that some basic research/planning first is *always* the wise thing to do.
.
So you're saying pumps like this that come with a new filter to swap in won't work? https://www.racingbeateurope.com/maz...kit-1057-p.asp
My rx8 currently experiences fuel starvation when tank hits below 50% full. If my fuel pump is dying, then the recommended fix is to spend over $400 on the series 2 N3R1-13-35Z? plus the modifications, which may be an extra $30 or so. What are the symptoms if just the fine filter is clogged?
My rx8 currently experiences fuel starvation when tank hits below 50% full. If my fuel pump is dying, then the recommended fix is to spend over $400 on the series 2 N3R1-13-35Z? plus the modifications, which may be an extra $30 or so. What are the symptoms if just the fine filter is clogged?
Symptoms .... my guess (and it's only a guess) is the symptoms with a clogged fine filter are the same as if the gauze filter were clogged. It's difficult to be sure on this because most of the time the gauze filter blocks first and it's prudent to just replace the whole thing rather than risk it.
Registered
Joined: Aug 2022
Posts: 68
Likes: 7
Depends ..... if you aren't tracking the car, replacing the pump with a stock S1 pump will suffice. If you are tracking it .... S2 pump is far superior and will allow high speed cornering with less fuel in the tank.
Symptoms .... my guess (and it's only a guess) is the symptoms with a clogged fine filter are the same as if the gauze filter were clogged. It's difficult to be sure on this because most of the time the gauze filter blocks first and it's prudent to just replace the whole thing rather than risk it.
Symptoms .... my guess (and it's only a guess) is the symptoms with a clogged fine filter are the same as if the gauze filter were clogged. It's difficult to be sure on this because most of the time the gauze filter blocks first and it's prudent to just replace the whole thing rather than risk it.
[QUOTE=mangomikey;5006971]Is the "fine filter" and "gauze filter" you're talking about housed inside the fuel pump unit?
Yes, the gauze sits below the pump and the fine filter surrounds it.
Yes, the gauze sits below the pump and the fine filter surrounds it.
