Brettus turbo 11
#1
Brettus turbo 11
Thought I may as well start a new thread for this seeing as there are significant differences between this set up and the last .
Engine :
Doweled
RX7 (deep) ALS apex seals
Brettspeed modified centre port runner (removed after unsuccessfull tests)
Rx8 performance engine mounts
Turbo :
Rebuilt Greddy
60-1 compressor wheel (same as BNR)
Clipped turbine
fabricated 60mm intake tube
internally polished Greddy outlet pipe
600x260x75 Intercooler
Gearbox :
5 speed ex JDM RX8
Ratios :
5 speed vs 6 speed g/box
1/3.483..............3.76
2/2.015...............2.27
3/1.391...............1.54
4/1.00...............1.19
5/0.76...............1.00
6/.....................0.84
Clutch
Exeddy stage 1
Fuel :
Walbro 255 pump
yellow/yellow/blue injectors
upgraded 06/2013 to yellow/blue/uncapped yellow 380/480/600
Tuning :
Mazdaedit/Brettspeed
Engine is dressed and almost ready for install at time of writing . Currently just tidying up a few loose ends.
Goals :
350 WHP on 11PSI
12s 1/4 mile
last longer than the last engine : 40,000 miles
Engine :
Doweled
RX7 (deep) ALS apex seals
Brettspeed modified centre port runner (removed after unsuccessfull tests)
Rx8 performance engine mounts
Turbo :
Rebuilt Greddy
60-1 compressor wheel (same as BNR)
Clipped turbine
fabricated 60mm intake tube
internally polished Greddy outlet pipe
600x260x75 Intercooler
Gearbox :
5 speed ex JDM RX8
Ratios :
5 speed vs 6 speed g/box
1/3.483..............3.76
2/2.015...............2.27
3/1.391...............1.54
4/1.00...............1.19
5/0.76...............1.00
6/.....................0.84
Clutch
Exeddy stage 1
Fuel :
Walbro 255 pump
yellow/yellow/blue injectors
upgraded 06/2013 to yellow/blue/uncapped yellow 380/480/600
Tuning :
Mazdaedit/Brettspeed
Engine is dressed and almost ready for install at time of writing . Currently just tidying up a few loose ends.
Goals :
350 WHP on 11PSI
12s 1/4 mile
last longer than the last engine : 40,000 miles
Last edited by Brettus; 06-01-2013 at 07:57 PM.
#8
i just feel like you could take advantage of the boost with the 5speed. care to enlighten me on why you think he s2trans and 4.77 diff would be better?
#9
good luck Brett.
Nice work, did you grind those seals yourself? Glad to see you are almost done.
Looking forward to live online tuning session Brett has promised.
LOL Ok ... he didn't
Looks awesome Brett
LOL Ok ... he didn't
Looks awesome Brett
free maps!
looking forward to this thread. I am a little surprised you went with the 5 speed. I would have thought that the s2 trans and a 4:77 diff would have been used. See how much I know?
Thanks for keeping us updated, interested to see final results.
#11
Registered
iTrader: (3)
I do love my 6th gear for the interstate cruising! But certainly understand your position and in that case the 5 speed makes good sense.
For 350 rwhp I thought you would need more injector flow than yellows and blues would give?
Are any of them un capped?
Really looking forward in seeing what kind of exhaust setup you end up with also.
Are you going to be doing any oil passageway/regulator work? Any oil pump work?
I know yall have cool temps where you live ( beautiful country!) but any waterjacket work to be done?
Cam ( Pettit racing) swears by increasing the coolant flow around the sparkplugs. I actually have a "freezeplug" looking plug between the lead/trailing sparkplugs where he accessed the coolant jackets and did his work on increasing the coolant flow in that area. I thought I would share that with you just in case you may be interested in doing the same.
At this power level are you still planning on using the oem ignition coils?
I have a feeling this will be a long and informative thread.
For 350 rwhp I thought you would need more injector flow than yellows and blues would give?
Are any of them un capped?
Really looking forward in seeing what kind of exhaust setup you end up with also.
Are you going to be doing any oil passageway/regulator work? Any oil pump work?
I know yall have cool temps where you live ( beautiful country!) but any waterjacket work to be done?
Cam ( Pettit racing) swears by increasing the coolant flow around the sparkplugs. I actually have a "freezeplug" looking plug between the lead/trailing sparkplugs where he accessed the coolant jackets and did his work on increasing the coolant flow in that area. I thought I would share that with you just in case you may be interested in doing the same.
At this power level are you still planning on using the oem ignition coils?
I have a feeling this will be a long and informative thread.
#12
The 5th in the 5 speed is taller than 6th so i can see it being better for cruiseing . All the other gears are taller - which i think will be a good thing as well .
I know yall have cool temps where you live ( beautiful country!) but any waterjacket work to be done?
Cam ( Pettit racing) swears by increasing the coolant flow around the sparkplugs. I actually have a "freezeplug" looking plug between the lead/trailing sparkplugs where he accessed the coolant jackets and did his work on increasing the coolant flow in that area. I thought I would share that with you just in case you may be interested in doing the same.
.
Cam ( Pettit racing) swears by increasing the coolant flow around the sparkplugs. I actually have a "freezeplug" looking plug between the lead/trailing sparkplugs where he accessed the coolant jackets and did his work on increasing the coolant flow in that area. I thought I would share that with you just in case you may be interested in doing the same.
.
Do you have that OD ?
Nope - I have had D585s on for about a year now.
#17
Registered
iTrader: (3)
Yep I do have that cooling jacket mod Bret. Cam told me it prevents the housing cracks around the sparkplugs that are sometimes seen.
Sorry I didnt realize you had the d 585's.....
You may want to ditch the oem midpipe--gutted or not. I think you will find that there is an advantage to a true 3 inch exhaust and one with straighter angles.
I will pM you.
Sorry I didnt realize you had the d 585's.....
You may want to ditch the oem midpipe--gutted or not. I think you will find that there is an advantage to a true 3 inch exhaust and one with straighter angles.
I will pM you.
Last edited by olddragger; 01-03-2013 at 04:47 PM.
#22
Un-Registered User
#24
Un-Registered User
#25
Good luck with the new build, look forward to seeing progress, and the tear down of the old engine, they may be a whole other thread though!
I didn't know JDM had 5 speed rx8 trannys, is it really a rx7 tranny?
I didn't know JDM had 5 speed rx8 trannys, is it really a rx7 tranny?
