DIY: Transmission and Differential fluid replacement
12-05-2008, 07:57 PM
#226
Rotary Crawfish
Walmart has the pump needed for this job in the outboard motor lower unit oil area.I
f you have the car on ramps there is no problems pumping in the oil, If you do you is a wimp!!!!
Put the F$#%$#^$#^#%^#%^ing washers back on the plugs and tighten the **** up!@!!!!
This ain't the Space shuttle folks, if you tighten the damn plug it should not leak.
f you have the car on ramps there is no problems pumping in the oil, If you do you is a wimp!!!!
Put the F$#%$#^$#^#%^#%^ing washers back on the plugs and tighten the **** up!@!!!!
This ain't the Space shuttle folks, if you tighten the damn plug it should not leak.
12-13-2008, 02:36 PM
#227
Grand Chancellor
Those with AT...
I noticed some folks are posting about what oil to use for AT. This rx-8 (06+) uses a similar type Aisin tranny as the Mazda6 6spd AT.
The tranny oil is Type-IV. As such it is critical to not use Mercon-V or anything else for this AT.
You can get this fluid from Toyota (Type-IV) or Mobil 1 JWS3309.
For more info see http://forum.mazda6club.com/index.php?showtopic=24510
The tranny oil is Type-IV. As such it is critical to not use Mercon-V or anything else for this AT.
You can get this fluid from Toyota (Type-IV) or Mobil 1 JWS3309.
For more info see http://forum.mazda6club.com/index.php?showtopic=24510
12-15-2008, 01:46 AM
#228
Registered User
Join Date: May 2008
Location: Pensacola, FL
Posts: 6
Likes: 0
Received 0 Likes
on
0 Posts
Thanks to everyone who put there threads online I did my 2 fluid changes within 1hour. the only problem I had was I used a milk jug and not a soda bottle for the 2oils. So the pump I used said any gallon including milk containers but I didn't so I had to pump and hold the pump together in the jug but all in all it work just fine. no mess. Thanks again for everything, you guys rock. RX-8 Club is the best.
02-15-2009, 05:06 PM
#230
Row faster, I hear banjos
iTrader: (5)
Join Date: Jul 2003
Location: Charlottesville, VA
Posts: 2,217
Likes: 0
Received 0 Likes
on
0 Posts
Changed out my 6MT and read diff fluid today. Very straight forward and easy. Used the ramps on the inclined driveway idea.
Around page 7 someone mentioned they used a 22mm socket for everything. On my '06 RX-8, I needed a 24mm socket (15/16ths).
Around page 7 someone mentioned they used a 22mm socket for everything. On my '06 RX-8, I needed a 24mm socket (15/16ths).
02-18-2009, 07:42 PM
#231
Super Moderator
Did my Trans (Manual 6 Speed) and Diff at 4000KM (2400Miles) a few days ago with Redline MT90 and 75W90 Gear Oil for Diff.
I can't get over the difference, bloody beautiful!, the changes are so smooth, no knotchiness, no 2nd gear lockout (when Cold).
And this is something I did not believe from others the car is quieter, smoother, funtastic!
Highly recommend this one!
Series II RX-8's
Transmission takes a 24mm (15/16th) socket, fill and drain plugs.
Differential Takes same 24mm for Drain, and a 23mm Ring spanner for FILL, as you cant fit a socket and wrench on the fill plug. (not enough room)
Ash
I can't get over the difference, bloody beautiful!, the changes are so smooth, no knotchiness, no 2nd gear lockout (when Cold).
And this is something I did not believe from others the car is quieter, smoother, funtastic!
Highly recommend this one!
Series II RX-8's
Transmission takes a 24mm (15/16th) socket, fill and drain plugs.
Differential Takes same 24mm for Drain, and a 23mm Ring spanner for FILL, as you cant fit a socket and wrench on the fill plug. (not enough room)
Ash
02-20-2009, 02:07 AM
#232
Registered User
Join Date: Dec 2006
Location: Adelaide
Posts: 40
Likes: 0
Received 0 Likes
on
0 Posts
went to the dealer to get my service done.. I also got them to change the diff and transmittion oil while they were at it...
I supplied 2 x Redline MT90 and 2 x redline 75w90 diff oil..
The stuipid idiots manage to put 1 x MT90 and 1 x 75w90 into the diff and
1 x MT90 and 1 x 75w90 into the transmittion how stupid is that....how can you mix the 2 different oils up?? read the bloody label
Is this going to be a problem? im getting the fluids drained and replaced in 3 days time...
I supplied 2 x Redline MT90 and 2 x redline 75w90 diff oil..
The stuipid idiots manage to put 1 x MT90 and 1 x 75w90 into the diff and
1 x MT90 and 1 x 75w90 into the transmittion how stupid is that....how can you mix the 2 different oils up?? read the bloody label
Is this going to be a problem? im getting the fluids drained and replaced in 3 days time...
02-20-2009, 02:41 AM
#233
Super Moderator
went to the dealer to get my service done.. I also got them to change the diff and transmittion oil while they were at it...
I supplied 2 x Redline MT90 and 2 x redline 75w90 diff oil..
The stuipid idiots manage to put 1 x MT90 and 1 x 75w90 into the diff and
1 x MT90 and 1 x 75w90 into the transmittion how stupid is that....how can you mix the 2 different oils up?? read the bloody label
Is this going to be a problem? im getting the fluids drained and replaced in 3 days time...
I supplied 2 x Redline MT90 and 2 x redline 75w90 diff oil..
The stuipid idiots manage to put 1 x MT90 and 1 x 75w90 into the diff and
1 x MT90 and 1 x 75w90 into the transmittion how stupid is that....how can you mix the 2 different oils up?? read the bloody label
Is this going to be a problem? im getting the fluids drained and replaced in 3 days time...
Sounds like your dealership also employs Lawn-mower Mechanic to work on Mazda's...
How and the hell does anyone get that wrong?
Does the guy have a IQ Bigger than his/her shoe size or not?
YES, Get it out...
There may not be an issue, but I recall reading that 75W90 in the transmission is too slippery and you could have synchro changing problems, like not engaging correctly or crunching...
But, because they have been diluted I don't think you will have a problem in the mean time......
UNBELIEVABLE!!!
3 Days time will be OK, I would think..
Hope his Helps...
ASH
02-20-2009, 02:44 AM
#234
Super Moderator
went to the dealer to get my service done.. I also got them to change the diff and transmittion oil while they were at it...
I supplied 2 x Redline MT90 and 2 x redline 75w90 diff oil..
The stuipid idiots manage to put 1 x MT90 and 1 x 75w90 into the diff and
1 x MT90 and 1 x 75w90 into the transmittion how stupid is that....how can you mix the 2 different oils up?? read the bloody label
Is this going to be a problem? im getting the fluids drained and replaced in 3 days time...
I supplied 2 x Redline MT90 and 2 x redline 75w90 diff oil..
The stuipid idiots manage to put 1 x MT90 and 1 x 75w90 into the diff and
1 x MT90 and 1 x 75w90 into the transmittion how stupid is that....how can you mix the 2 different oils up?? read the bloody label
Is this going to be a problem? im getting the fluids drained and replaced in 3 days time...
Who was the Dealer, Paradise, Australian, let me guess City Mazda?
Where did you buy your Redline from?
02-20-2009, 03:05 AM
#235
Registered User
Join Date: Dec 2006
Location: Adelaide
Posts: 40
Likes: 0
Received 0 Likes
on
0 Posts
Hi mate...
I thought that Paradise motors would have been a sure bet because i heard so many bad stories about the other dealers and not them ...
BUT I have been getting my car serviced at Paradise Motors and they stuffed up... they didnt even give me the spare rotary oil and the service department tried to cover the mistake up by lying to me... So disappointing...
I got my oil from www.performancelub.com.. they are in QLD and the guy's name is Harold... ordered the oil and spark plugs from him and they arrived pretty quickly.. he's pretty good...
I thought that Paradise motors would have been a sure bet because i heard so many bad stories about the other dealers and not them ...
BUT I have been getting my car serviced at Paradise Motors and they stuffed up... they didnt even give me the spare rotary oil and the service department tried to cover the mistake up by lying to me... So disappointing...
I got my oil from www.performancelub.com.. they are in QLD and the guy's name is Harold... ordered the oil and spark plugs from him and they arrived pretty quickly.. he's pretty good...
02-20-2009, 03:16 AM
#236
Super Moderator
Wow, Paradise...they are usually the best, and lying? Reg and David Neale owners are Christians!, they would not lie!
I nearly bought my 8 there in November 08, but the guy was only half interested and wanted me to sign the deal with my offer first, then the old, the boss won't agree, you have to give us more to work with..they lost out, I went to Australian, did not want to, but got the best deal.
The Salesman is a Mazda NUT!!, he sells more Mazda's than anyone else in Adelaide and one of the best in Australia, he's been work there for 15 years and never had a Holiday!
I nearly bought my 8 there in November 08, but the guy was only half interested and wanted me to sign the deal with my offer first, then the old, the boss won't agree, you have to give us more to work with..they lost out, I went to Australian, did not want to, but got the best deal.
The Salesman is a Mazda NUT!!, he sells more Mazda's than anyone else in Adelaide and one of the best in Australia, he's been work there for 15 years and never had a Holiday!
02-20-2009, 03:54 AM
#237
Registered User
Join Date: Dec 2006
Location: Adelaide
Posts: 40
Likes: 0
Received 0 Likes
on
0 Posts
its a shame then that the owners of the dealership don't work in the service department ...congrats on the car.. looks great...
Last edited by Henley; 02-20-2009 at 03:57 AM.
02-21-2009, 07:27 PM
#238
MMMMM............BACON!
Join Date: Feb 2009
Location: Clarksville, TN
Posts: 10
Likes: 0
Received 0 Likes
on
0 Posts
So I just changed my transmission and differential fluid today with Royal Purple Max Gear 75w-90. I was always a little skeptical about performance increase claims just from fluid change, but the car now drives smoother, quieter with what seems to be faster acceleration. The shifting doesn't really feel any different (always been smooth for me anyways) but again the whole car just feels faster and overall better.............less mechanical resistance perhaps?!?!
02-21-2009, 10:55 PM
#239
Lotus Wannabe
Join Date: Jun 2008
Location: Seattle
Posts: 38
Likes: 0
Received 0 Likes
on
0 Posts
Tranny Overfill?
I replaced my tranny and rear diff fluids today. The DIY says 1.8 quarts for the tranny, but I put a full 2 quarts in. I am wondering if this is ok?
03-18-2009, 03:01 PM
#240
I found the best way to fill it was with a long clear tube. I just popped the hood and ran it down beside the oil filter. From underneath, grab it and put it into the top hole. From the engine bay, fill the oil. On the differential, just loop it over the coilovers down to the fill hole. You can fill it above the tire.
About to hit 30k on original fluids. I'll be doing this soon and post up my thoughts.
03-25-2009, 11:01 AM
#242
duct tape works wonders
Join Date: Sep 2006
Location: Snohomish, WA
Posts: 225
Likes: 0
Received 0 Likes
on
0 Posts
Okay now you got me interested.
I recently replaced my trans fluid and was hoping that shifting gears won't be as crunchy. To my surprise it still feels crunchy even when I replaced the trans fluid. Will regreasing the shifter cup fix that?
I recently replaced my trans fluid and was hoping that shifting gears won't be as crunchy. To my surprise it still feels crunchy even when I replaced the trans fluid. Will regreasing the shifter cup fix that?
03-25-2009, 05:59 PM
#243
Just completed the fluid change out yesterday. Drove a good amount today. Shifts are defiantly smoother. Nothing insane, but about what I expected. Totally worth the $40 in fluids between the trans and diff. If for nothing else, piece of mind that I now have a higher quality full synthetic fluid protection.
03-25-2009, 10:24 PM
#244
2005 Black RX-8 GT 6M
Join Date: Jul 2006
Location: San Jose Area
Posts: 6,350
Likes: 0
Received 0 Likes
on
0 Posts
Stick with Redline or Amsoil GL-4 products.
I bought Amsoil and am going to put it in within the next month or so.
04-16-2009, 03:45 PM
#246
Registered
iTrader: (1)
Join Date: Nov 2007
Location: Akron Ohio
Posts: 110
Likes: 0
Received 0 Likes
on
0 Posts
Yes, it definitely is. They're called crush washers. When you torque the plugs, it crushes the washer and forms a tight seal. Using the same ones won't get you a proper seal and may cause leaks because the washer has already been crushed to most of its potential. They should only be a few bucks each at your Mazda dealer. And they should usually have them in stock because they perform this kind of maintenance on cars probably daily.
Has anyone had success sourcing these washers from any place other than a Mazda Dealership?
(such a frustrating problem to have)
04-16-2009, 04:03 PM
#247
zoom zoom
Join Date: Apr 2005
Location: CA
Posts: 707
Likes: 0
Received 0 Likes
on
0 Posts
I went to order the crush washers from a Mazda Dealership, and they quoted me a total of $22 for 4 of them (2-at $7.00 and 2-at $4). I thought that was ridiculous, so I discussed with Summit Racing and Auto Zone. I gave them crush washer part # 9956-41-800, and also mentioned I thought they were 18mm (inner diameter). Neither place could match the part number up with generic items.
Has anyone had success sourcing these washers from any place other than a Mazda Dealership?
(such a frustrating problem to have)
Has anyone had success sourcing these washers from any place other than a Mazda Dealership?
(such a frustrating problem to have)
04-16-2009, 04:47 PM
#248
Finishline rocks...
OnlineMazdaparts.com is also a great place! (over $100 gets free shipping most of the time... some parts excluded)
http://www.trademotion.com/partlocat...&siteid=214264
...do a search for the part number::::
Which are both dealerships...
OnlineMazdaparts.com is also a great place! (over $100 gets free shipping most of the time... some parts excluded)
http://www.trademotion.com/partlocat...&siteid=214264
...do a search for the part number::::
Which are both dealerships...
Last edited by BoosTED; 04-16-2009 at 04:50 PM.
04-16-2009, 04:51 PM
#249
i went to order the crush washers from a mazda dealership, and they quoted me a total of $22 for 4 of them (2-at $7.00 and 2-at $4). I thought that was ridiculous, so i discussed with summit racing and auto zone. I gave them crush washer part # 9956-41-800, and also mentioned i thought they were 18mm (inner diameter). Neither place could match the part number up with generic items.
Has anyone had success sourcing these washers from any place other than a mazda dealership?
(such a frustrating problem to have)
Has anyone had success sourcing these washers from any place other than a mazda dealership?
(such a frustrating problem to have)
