I'm looking for a photographic comparison between the Revi duct and the stock duct that feeds the airbox. I've seen the picture that RB posts on the website, but I'd like to see side by side pictures. I'm trying to figure out why the Revi is more effective. I know the VFAD is gone but what else makes it better?
And this is for anyone who says "use the search feature "....
And this is for anyone who says "use the search feature "....
04-26-2006, 03:29 PM
#2
The Duct ? or REvi ? They're 2 different things.
If you're talking about the Duct, IT direct air in the FRONT of your car instead of the VFAD on the side. Meaning as your car moves, the air will blow directly into the duct and transfe it to your Intake. Without the control of the VFAD you will be sure that you will always get the most cold air you can have.
If you're talking about Revi. it directs air directly to MAF-Engine. and their design somehow "compress" the mass of air at the enterance. So that way, more air into the engine (instead of the stock Airbox's leave-it-as-is design)
If you're talking about the Duct, IT direct air in the FRONT of your car instead of the VFAD on the side. Meaning as your car moves, the air will blow directly into the duct and transfe it to your Intake. Without the control of the VFAD you will be sure that you will always get the most cold air you can have.
If you're talking about Revi. it directs air directly to MAF-Engine. and their design somehow "compress" the mass of air at the enterance. So that way, more air into the engine (instead of the stock Airbox's leave-it-as-is design)
04-26-2006, 04:24 PM
#3
here is the RB duct installed with the front bumper cover removed. The OE VFAD duct resides behind the black rectangular plastic piece shown above the RB duct in this photo, it was removed to install the RB duct though
