VersaTune's Shop Car Tuning Journey

Old 01-05-2019, 05:19 PM
  #1
RX8Club.com Sponsor
Thread Starter

Steve@VersaTune's Avatar

Join Date: Mar 2017
Posts: 145
Thanks: 0
Thanked 23 Times in 21 Posts
VersaTune's Shop Car Tuning Journey

I thought I'd start a new thread to journal the progress of our shop car. Enjoy the ride as we move from stock to lightly modified to all-out turbo performance. We will build tunes and add them to our tuning database as we go, making it easy for others to replicate our results.

Our shop car is a 2004 RX-8 with just under 90,000 miles on the chassis. The engine is a Mazda reman engine with less than 10,000 miles on it.

On the dyno for the first time.


The dyno results - as purchased 100% stock and unmodified.


Last edited by [email protected]; 01-14-2019 at 09:00 AM.
Steve@VersaTune is offline
The Following User Says Thank You to [email protected] For This Useful Post:
NotAPreppie (01-05-2019)
Old 01-05-2019, 05:25 PM
  #2
RX8Club.com Sponsor
Thread Starter

Steve@VersaTune's Avatar

Join Date: Mar 2017
Posts: 145
Thanks: 0
Thanked 23 Times in 21 Posts
Our first step is to establish a healthy stock baseline. In the first dyno, I noticed some jitter at high RPMs which lead me to believe that there was something not quite right with the ignition. So, we ordered a fresh set of stock coils and NGK plugs and wires.
The new ignition parts are in. Here are the old ones. Note the hot spots on the coils.


A new stock replacement air filter is on order as well. The mfg date on this one is 2012.

Last edited by [email protected]; 01-05-2019 at 10:35 PM.
Steve@VersaTune is offline
Old 01-05-2019, 10:20 PM
  #3
Registered
iTrader: (9)

Chrishoky's Avatar

Join Date: May 2010
Location: North Wales, PA
Posts: 1,029
Thanked 6 Times in 6 Posts
This is a cool idea, but why are the images so small? I cant view the dyno results at all in the first post. Im curious what the stock car made.
Chrishoky is offline
Old 01-05-2019, 10:32 PM
  #4
RX8Club.com Sponsor
Thread Starter

Steve@VersaTune's Avatar

Join Date: Mar 2017
Posts: 145
Thanks: 0
Thanked 23 Times in 21 Posts
challenges with posting images. Fixed

Last edited by [email protected]; 01-05-2019 at 10:35 PM.
Steve@VersaTune is offline
Old 01-06-2019, 05:48 AM
  #5
Zoom-Freakin'-Zoom
iTrader: (5)

swoope's Avatar

Join Date: Jan 2004
Location: orlando, fl
Posts: 14,583
Thanked 22 Times in 19 Posts
wow,

this is best, needed thread for elders thinking about it.

shameless bump

beers
swoope is offline
Old 01-06-2019, 11:30 PM
  #6
Registered
iTrader: (9)

Chrishoky's Avatar

Join Date: May 2010
Location: North Wales, PA
Posts: 1,029
Thanked 6 Times in 6 Posts
Originally Posted by [email protected] View Post
challenges with posting images. Fixed
These images are much better, but the dyno chart seems to be missing now? Can you post it again or at least let us know the numbers the stock car made?
Chrishoky is offline
Old 01-06-2019, 11:37 PM
  #7
RX8Club.com Sponsor
Thread Starter

Steve@VersaTune's Avatar

Join Date: Mar 2017
Posts: 145
Thanks: 0
Thanked 23 Times in 21 Posts
Try refreshing the page. The dyno is there for me.

Wheel Torque T (Ft-Lbs) 120 @ 5651 RPM
Wheel Power T (HP) 170 @ 8170 RPM

Compression tester is on the way too.
Steve@VersaTune is offline
The Following 2 Users Say Thank You to [email protected] For This Useful Post:
Chrishoky (01-07-2019), TomD_Cincy (01-07-2019)
Old 01-07-2019, 07:11 PM
  #8
Registered
iTrader: (2)

Join Date: Mar 2010
Location: Cincinnati, OH
Posts: 85
Thanked 6 Times in 6 Posts
Originally Posted by [email protected] View Post
Try refreshing the page. The dyno is there for me.

Wheel Torque T (Ft-Lbs) 120 @ 5651 RPM
Wheel Power T (HP) 170 @ 8170 RPM

Compression tester is on the way too.

Will you be retesting after putting the new coils and filter in and before any tuning?

Last edited by TomD_Cincy; 01-07-2019 at 07:14 PM. Reason: changed comment
TomD_Cincy is offline
Old 01-07-2019, 07:29 PM
  #9
RX8Club.com Sponsor
Thread Starter

Steve@VersaTune's Avatar

Join Date: Mar 2017
Posts: 145
Thanks: 0
Thanked 23 Times in 21 Posts
Yes
Steve@VersaTune is offline
Old 01-08-2019, 07:37 AM
  #10
Registered

trackjunkie's Avatar

Join Date: Oct 2017
Location: South Central PA
Posts: 284
Thanked 9 Times in 9 Posts
any plans on tuning on E85 or add more tables to versatner to support E85?
thanks,
trackjunkie is offline
Old 01-08-2019, 07:40 AM
  #11
^^^ Fluent in snark.

NotAPreppie's Avatar

Join Date: Mar 2006
Location: Chicago, IL, USA, North America, Earth, Sol System, Sector ZZ9 Plural Z Alpha, Milkyway, Universe
Posts: 3,131
Thanked 398 Times in 325 Posts
Steve,

Thanks for doing all of this! It's something I've really wanted to do but lack access to a dyno.

Signed,
Every '8 owner ever, whether they know it or not.
NotAPreppie is online now
The Following 2 Users Say Thank You to NotAPreppie For This Useful Post:
Chrishoky (01-08-2019), Tamas (01-08-2019)
Old 01-12-2019, 03:59 PM
  #12
RX8Club.com Sponsor
Thread Starter

Steve@VersaTune's Avatar

Join Date: Mar 2017
Posts: 145
Thanks: 0
Thanked 23 Times in 21 Posts
Originally Posted by trackjunkie View Post
any plans on tuning on E85 or add more tables to versatner to support E85?
thanks,
We'll probably do E85.
Steve@VersaTune is offline
Old 01-12-2019, 04:03 PM
  #13
RX8Club.com Sponsor
Thread Starter

Steve@VersaTune's Avatar

Join Date: Mar 2017
Posts: 145
Thanks: 0
Thanked 23 Times in 21 Posts
The stock tune-up is done.
We installed new stock replacement plugs, wires, coils, and air filter. It felt smoother after the tune-up. I thought it was placebo effect until I saw the dyno. +9HP!

Here is the dyno:



Last edited by [email protected]; 01-17-2019 at 08:22 AM. Reason: corrected dyno sheet showing tune-up plot vs baseline with positive gains.
Steve@VersaTune is offline
The Following User Says Thank You to [email protected] For This Useful Post:
kevink0000 (01-14-2019)
Old 01-12-2019, 04:11 PM
  #14
Boosted Kiwi
iTrader: (2)

Brettus's Avatar

Join Date: Apr 2006
Location: Y-cat-o NZ
Posts: 18,269
Thanked 212 Times in 164 Posts
Good work ... IMO too much comparison is done, when fitting aftermarket parts, with old worn out stock parts ...............
Brettus is offline
Old 01-12-2019, 04:17 PM
  #15
RX8Club.com Sponsor
Thread Starter

Steve@VersaTune's Avatar

Join Date: Mar 2017
Posts: 145
Thanks: 0
Thanked 23 Times in 21 Posts
Thanks. I'm trying to make this as repeatable as possible.
I wanted to create a healthy stock baseline to use for comparison. I have a rotary compression tester, but the lift was busy today. I'll do a compression test soon.

The VersaTuner performance tune for a 100% stock car is coming soon!
Steve@VersaTune is offline
Old 01-14-2019, 08:53 AM
  #16
Registered

kevink0000's Avatar

Join Date: Sep 2017
Location: Arizona
Posts: 84
Thanked 6 Times in 4 Posts
Steve,

Can you repost the second dyno chart after the coil change? Its very small.

Thanks much for doing these progressive tests. It is very helpful.
kevink0000 is offline
Old 01-14-2019, 08:54 AM
  #17
RX8Club.com Sponsor
Thread Starter

Steve@VersaTune's Avatar

Join Date: Mar 2017
Posts: 145
Thanks: 0
Thanked 23 Times in 21 Posts
Fixed.

Last edited by [email protected]; 01-14-2019 at 09:01 AM.
Steve@VersaTune is offline
The Following User Says Thank You to [email protected] For This Useful Post:
kevink0000 (01-14-2019)
Old 01-15-2019, 11:10 PM
  #18
RX8Club.com Sponsor
Thread Starter

Steve@VersaTune's Avatar

Join Date: Mar 2017
Posts: 145
Thanks: 0
Thanked 23 Times in 21 Posts
We ran a half a tank of fuel through the RX-8 on the dyno last night doing dozens of dyno pulls. We confirmed a lot of RX-8 tuning beliefs. Timing doesn't really do much on stock RX-8s. Leaner AFRs make some power, but you need to keep the health of the catalytic converter in mind and not get too crazy. Rotaries have high EGTs! More to come as we continue development of the RX-8 tunes.
Steve@VersaTune is offline
Old 01-16-2019, 12:28 AM
  #19
Senior Member
iTrader: (9)

Xero Ryuu's Avatar

Join Date: Dec 2010
Location: Bakersfield, CA
Posts: 1,195
Thanked 22 Times in 21 Posts
I have a question, as well as a potential additional test you could perform.

Question: Are you using a premix on this motor? If so, what oil and to what ratio; and if not, why not?

Test: Does premixing your fuel affect horsepower/output. Its generally accepted that premixing has an affect on octane amongst other fuel characteristics, however the benefits of premixing are also well known and generally accepted as a beneficial habit. It would be interesting to have a comparison using healthy motor where any differences may have a more noticable difference (as a percentage decrease, or possibly percentage increase, who knows)

Good luck,
Ricky
Xero Ryuu is offline
Old 01-16-2019, 06:44 AM
  #20
RX8Club.com Sponsor
Thread Starter

Steve@VersaTune's Avatar

Join Date: Mar 2017
Posts: 145
Thanks: 0
Thanked 23 Times in 21 Posts
We have not tested with pre-mixing yet. We have not experienced any knock with stock or advanced timing. We can test pre-mixing to see if there is any difference.
Steve@VersaTune is offline
Old 01-16-2019, 07:32 AM
  #21
Moder8
iTrader: (1)

04Green's Avatar

Join Date: Aug 2009
Location: Oviedo, Florida
Posts: 2,543
Thanked 32 Times in 22 Posts
Great Idea, Following...

Am also interested in the Pre-Mix concepts. Butt Dyno says yes, including a different exhaust note. Then factor in the F1 "Oil Leak" scandal...

One question, and no problem discussing off line, but do you have an idea of how close you % Load line is to your Calculated Max Load Line? Specifically around 6,000 RPM on a Stock Motor?
04Green is offline
Old 01-16-2019, 08:15 AM
  #22
RX8Club.com Sponsor
Thread Starter

Steve@VersaTune's Avatar

Join Date: Mar 2017
Posts: 145
Thanks: 0
Thanked 23 Times in 21 Posts
The max load I've seen is 1.07 at 5900 with ECT 73C and IAT 20C. The engine was still a little on the cool side. Typical peak load is around 1.035 with normal ECT and room temperature IATs.
I don't log percent of max calc load. It's an arbitrary value.
Steve@VersaTune is offline
Old 01-17-2019, 08:19 AM
  #23
RX8Club.com Sponsor
Thread Starter

Steve@VersaTune's Avatar

Join Date: Mar 2017
Posts: 145
Thanks: 0
Thanked 23 Times in 21 Posts
Here is the dyno sheet for our new tune for a 100% stock RX-8. The tune will be in the tune database later today.



Steve@VersaTune is offline
Old 01-17-2019, 09:29 AM
  #24
^^^ Fluent in snark.

NotAPreppie's Avatar

Join Date: Mar 2006
Location: Chicago, IL, USA, North America, Earth, Sol System, Sector ZZ9 Plural Z Alpha, Milkyway, Universe
Posts: 3,131
Thanked 398 Times in 325 Posts
Looks like you changed the APV and VDI timing to open a little later.
NotAPreppie is online now
Old 01-17-2019, 09:30 AM
  #25
RX8Club.com Sponsor
Thread Starter

Steve@VersaTune's Avatar

Join Date: Mar 2017
Posts: 145
Thanks: 0
Thanked 23 Times in 21 Posts
Originally Posted by NotAPreppie View Post
Looks like you changed the APV and VDI timing to open a little later.
I didn't move the APV, just the VDI. I tried moving the APV around, it didn't help.
Steve@VersaTune is offline
