HID Fog Lights Installed!!!
03-16-2005, 07:55 PM
#27
503wtq Boosted Bimmer
Thread Starter
iTrader: (2)
Join Date: Oct 2004
Location: Los Angeles, California
Posts: 3,038
Likes: 0
Received 0 Likes
on
0 Posts
omicron, yea, i dunno who i was responding to in that last post..... but anyway, here is the deal. It was a pain in the *** to install these. Here's why...
1) They are rebased D2S bulbs fitted with a H11 socket.
2) The H11 HID bulbs are too long to fit into the stock housing. I had to strech the reflector inside the housing which means the whole fog light had to come off the car.
3) Lack of mounting options for the ballast forced me to drill holes in it and attach it to the oil cooler bracket.
4) Trying to aim these was very hard also. Trying to make them not intrusive to other drivers forced me to aim them pretty low.
The whole install took about 3 hours, mainly beaucse I took my time and did a very professional job. If you look at the pictures in my second post you can see where I mounted the ballast. ( its the silver box) Lastly, they do make a rebased H9 bulb.
1) They are rebased D2S bulbs fitted with a H11 socket.
2) The H11 HID bulbs are too long to fit into the stock housing. I had to strech the reflector inside the housing which means the whole fog light had to come off the car.
3) Lack of mounting options for the ballast forced me to drill holes in it and attach it to the oil cooler bracket.
4) Trying to aim these was very hard also. Trying to make them not intrusive to other drivers forced me to aim them pretty low.
The whole install took about 3 hours, mainly beaucse I took my time and did a very professional job. If you look at the pictures in my second post you can see where I mounted the ballast. ( its the silver box) Lastly, they do make a rebased H9 bulb.
Last edited by Rotary Rasp; 03-16-2005 at 07:59 PM.
03-17-2005, 02:35 AM
#31
Registered Laker's Fan
Join Date: Aug 2003
Location: By da beach, Cali.
Posts: 302
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by Rotary Rasp
It was a pain in the *** to install these. Here's why...
The whole install took about 3 hours, mainly beaucse I took my time and did a very professional job. If you look at the pictures in my second post you can see where I mounted the ballast. ( its the silver box) Lastly, they do make a rebased H9 bulb.
The whole install took about 3 hours, mainly beaucse I took my time and did a very professional job. If you look at the pictures in my second post you can see where I mounted the ballast. ( its the silver box) Lastly, they do make a rebased H9 bulb.
I have a 9006 HID kit left over from our Miata, you think I can install those into the 8 fogs? Love the way yours looks.
03-17-2005, 05:58 AM
#32
Who Cares?
Join Date: Dec 2003
Location: Robins Air Force Base, Georgia
Posts: 531
Likes: 0
Received 0 Likes
on
0 Posts
Very nice!! Looks really great. You said you had to stretch the lens...how exactly did you do that without damaging it? Also, did you take enough pictures to put together a step by step DIY thread??? This would make an excellent DIY thread! Please put one together for us.... :D
03-17-2005, 09:50 AM
#34
503wtq Boosted Bimmer
Thread Starter
iTrader: (2)
Join Date: Oct 2004
Location: Los Angeles, California
Posts: 3,038
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by momo
I have a 9006 HID kit left over from our Miata, you think I can install those into the 8 fogs? Love the way yours looks.
03-17-2005, 09:51 AM
#35
503wtq Boosted Bimmer
Thread Starter
iTrader: (2)
Join Date: Oct 2004
Location: Los Angeles, California
Posts: 3,038
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by Air Force RX8
Very nice!! Looks really great. You said you had to stretch the lens...how exactly did you do that without damaging it? Also, did you take enough pictures to put together a step by step DIY thread??? This would make an excellent DIY thread! Please put one together for us.... :D
03-21-2005, 06:02 AM
#38
Registered Laker's Fan
Join Date: Aug 2003
Location: By da beach, Cali.
Posts: 302
Likes: 0
Received 0 Likes
on
0 Posts
Dayum. I know that you have your fogs aimed down, but it almost appears that the HID fogs are brighter than the HID projectors?
Or does it just appear that way in the pics?
Or does it just appear that way in the pics?
04-09-2005, 11:30 AM
#49
503wtq Boosted Bimmer
Thread Starter
iTrader: (2)
Join Date: Oct 2004
Location: Los Angeles, California
Posts: 3,038
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by Omicron
Welp, I ordered my 9005 (high beam) HID kit yesterday. I'll let y'all know how it comes out!
Last edited by Rotary Rasp; 04-11-2005 at 01:42 AM.
04-09-2005, 06:01 PM
#50
Registered
Join Date: Oct 2001
Location: Boulder County, Colorado
Posts: 7,966
Likes: 0
Received 4 Likes
on
3 Posts
Originally Posted by Rotary Rasp
Omicron, that might be a problem. The HID lighting system takes about 10 seconds to reach its highest luminescence. That means you woun't be abe to flash your high beams at anyone. One of the main proplems with gas discharge lighting is the warm up time, remember how long it took for the street lights to start making light after they were turned on. (about 5-10 minutes) Thats were the infamous xenon comes in to play; xenon makes very little usable light, but it warms up very fast (about 5 seconds). Thats why when you first turn on your HIDs they appear bue, that is the color of the xenon. As they other gases warm up, mainly soduim, they over power the xenon. This explains why you have very little light when you first turn on HIDs. Do you see how this could be a problem?
Oh well... I rarely if ever flash my high beams at people, and would rather have LOTSA light when I'm on the back roads.
Hmmm... wonder if I could adapt this kit to install it in my fogs instead? Anyone know how close the 9005 and the H11 bases are?
